E-FLEX® Polyester Hose Protective Sleeve is made of self-renewing, abrasion-resistant polyester multifilament, which makes it extremely flexible, durable, abrasion resistant, explosion proof, and anti-corrosion. The cable sleeve is designed to protect hydraulic hoses and provides limited burst and containment protection.
| Part No | HPS-PES-S-T10 |
|---|---|
| Material | Polyester |
| Working Temperature: | -40℃ to 150℃ |
| Melt Point | 240+(-)10℃ |
| Flammability: | FMVSS 302 |
| Standard Color: | Black |
| Cutting Tool: | Hot Knife, Scissor |
Polyester Protective Hydraulic Hose Sleeve
E-FLEX® Protective Hydraulic Hose Sleeve made of self-renewing, abrasion-resistant polyester multifilament, which designed to protect hydraulic hoses and provide limited burst and containment protection.
Feature of protective hydraulic hose sleeve:
1. Superior Abrasion Resistance
Tightly Woven Polyester: Withstands friction from constant movement (e.g., excavator arms, conveyor systems).
Longer Hose Lifespan: Reduces surface wear by up to 70% compared to unprotected hoses.
2. Lightweight & Flexible
Easy Installation: Slides over existing hoses without tools.
Zero Mobility Restrictions: Maintains hose flexibility in dynamic applications.
3. Environmental Protection
UV-Resistant: Prevents sun degradation in outdoor equipment.
Oil & Moisture Repellent: Resists hydraulic fluids, grease, and water.
Physical Properties
| Material | Polyester |
| Working Temperature | -40℃ ~ +150℃ |
| Melt Point | 250 ± 10℃ |
| MSHA Compliance | MSHA IC293/01 |
| Blasting Resistance | Conform to ISO 3457 |
| Abrasion Resistance | Conform to ISO 6945 |
| Flammability | FMVSS 302 |
| Anti-leakage | Conform to SAE J343 |
| UV Resistant | Conform to BS EN 13758-1 |
| Standard Color | Black |
| Cutting Tool | Hot Knife, Scissor |
Product Size of Protective Hydraulic Hose Sleeve
| Part No. | I.D (mm) | Flat Width (mm) | Thickness (mm) | Packing (m/spool) |
|---|---|---|---|---|
| HPS-PES-S-017-BK-T10-PRT | 17 | 30 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-020-BK-T10-PRT | 20 | 35 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-023-BK-T10-PRT | 23 | 39 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-025-BK-T10-PRT | 25 | 42 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-027-BK-T10-PRT | 27 | 46 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-031-BK-T10-PRT | 31 | 52 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-033-BK-T10-PRT | 33 | 55 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-036-BK-T10-PRT | 36 | 60 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-040-BK-T10-PRT | 40 | 66 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-044-BK-T10-PRT | 44 | 72 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-047-BK-T10-PRT | 47 | 77 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-050-BK-T10-PRT | 50 | 82 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-053-BK-T10-PRT | 53 | 86 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-056-BK-T10-PRT | 56 | 91 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-060-BK-T10-PRT | 60 | 97 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-066-BK-T10-PRT | 66 | 107 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-073-BK-T10-PRT | 73 | 118 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-078-BK-T10-PRT | 78 | 126 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-085-BK-T10-PRT | 85 | 137 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-093-BK-T10-PRT | 93 | 149 | 1.0 ± 0.1 | 50 |
| HPS-PES-S-112-BK-T10-PRT | 112 | 179 | 1.0 ± 0.1 | 50 |
Application of Protective Hydraulic Hose Sleeve
1.Construction & Heavy Equipment: Excavators, cranes, loaders.
2.Agriculture: Tractors, harvesters, irrigation systems.
3.Manufacturing: Hydraulic presses, robotic arms, assembly lines.
4.Material Handling: Forklifts, conveyor belts, logging equipment.
