• Extend service intervals at known rubbing points
The sleeve takes routine surface contact that would otherwise act directly on the hydraulic hose cover.
• Add a more substantial textile wear layer
The nominal 1.0 mm wall provides added material between the hose and surrounding metalwork for general equipment protection.
• Stabilize routes that move during operation
Holding adjacent hoses in a defined bundle limits random contact as cylinders, arms or steering systems cycle.
1. Nominal 1.0 mm wall
Offers a thicker protective textile layer for routes with recurring mechanical contact.
2. Durable nylon yarn
Provides a flexible outer surface suited to normal machine movement and installation handling.
3. Full circumference coverage
Surrounds the hose or bundle so protection is not limited to one visible contact face.
4. Conformable tubular design
Follows bends and changing route directions when the sleeve diameter is selected correctly.
5. Bundle restraint
Keeps compatible hydraulic lines together and reduces loose movement between neighboring hoses.
6. Production-ready options
Can be supplied by roll or prepared as repeatable cut pieces with agreed identification and packaging.
| Material |
Nylon multifilament
|
| Working Temperature |
-40°C to +125°C |
| Melting Point |
220±10°C |
| Flammability |
FMVSS 302 |
| MSHA Compliance |
Refer to MSHA IC293/01 |
| Blasting Resistance |
Refer to ISO 3457 |
| Abrasion Resistance |
Refer to ISO 6945 |
| Anti-leakage |
Conform to SAE J343 |
| UV Resistant |
Conform to BS EN13758-1 |
| Standard Color |
Black |
| Cutting Tool |
Hot Knife |
Specifications
|
Part No
|
I.D
(mm)
|
Flat Width
(mm)
|
Wall
Thickness
(mm)
|
Packing
Length
(m/spool)
|
| HPS-NY-S-010-BK-T10 |
10 |
20 |
1.0±0.1
|
50 |
| HPS-NY-S-014-BK-T10 |
14 |
25 |
1.0±0.1 |
50 |
| HPS-NY-S-017-BK-T10 |
17 |
30 |
1.0±0.1 |
50 |
| HPS-NY-S-020-BK-T10 |
20 |
35 |
1.0±0.1 |
50 |
| HPS-NY-S-023-BK-T10 |
23 |
39 |
1.0±0.1 |
50 |
| HPS-NY-S-025-BK-T10 |
25 |
42 |
1.0±0.1 |
50 |
| HPS-NY-S-027-BK-T10 |
27 |
46 |
1.0±0.1 |
50 |
| HPS-NY-S-031-BK-T10 |
31 |
52 |
1.0±0.1 |
50 |
| HPS-NY-S-033-BK-T10 |
33 |
55 |
1.0±0.1 |
50 |
| HPS-NY-S-036-BK-T10 |
36 |
60 |
1.0±0.1 |
50 |
| HPS-NY-S-040-BK-T10 |
40 |
66 |
1.0±0.1 |
50 |
HPS-NY-S-044-BK-T10
|
44 |
72 |
1.0±0.1 |
50 |
| HPS-NY-S-047-BK-T10 |
47 |
77 |
1.0±0.1 |
50 |
| HPS-NY-S-050-BK-T10 |
50 |
80 |
1.0±0.1 |
50 |
| HPS-NY-S-053-BK-T10 |
53 |
86 |
1.0±0.1 |
50 |
HPS-NY-S-056-BK-T10
|
56 |
91 |
1.0±0.1 |
50 |
HPS-NY-S-060-BK-T10
|
60 |
97 |
1.0±0.1 |
50 |
HPS-NY-S-062-BK-T10
|
62 |
100 |
1.0±0.1 |
50 |
HPS-NY-S-066-BK-T10
|
66 |
107 |
1.0±0.1 |
50 |
HPS-NY-S-073-BK-T10
|
73 |
118 |
1.0±0.1 |
50 |
HPS-NY-S-078-BK-T10
|
78 |
126 |
1.0±0.1 |
50 |
HPS-NY-S-085-BK-T10
|
85 |
137 |
1.0±0.1 |
50 |
HPS-NY-S-090-BK-T10
|
90 |
145 |
1.0±0.1 |
50 |
HPS-NY-S-093-BK-T10
|
93 |
149 |
1.0±0.1 |
50 |
HPS-NY-S-102-BK-T10
|
102 |
165 |
1.0±0.1 |
50 |
HPS-NY-S-106-BK-T10
|
106 |
170 |
1.0±0.1 |
50 |
HPS-NY-S-112-BK-T10
|
112 |
179 |
1.0±0.1 |
50 |
HPS-NY-S-127-BK-T10
|
127 |
206 |
1.0±0.1 |
50 |
Typical Applications
Excavators loaders and access equipment
Addresses rubbing where hoses travel along booms, arms, lift structures and articulated joints.
Forklifts cranes and material handling machines
Reduces direct contact around masts, sheaves, guides and crowded hydraulic passages.
Agricultural and forestry equipment
Protects hose covers from vibration-driven scuffing near frames, implements and moving linkages.
Hydraulic presses and factory machinery
Organizes multiple lines and shields them from brackets, guards and nearby machine components.
Measure the maximum outside diameter of the individual hose or complete hose bundle, including fittings, clamps and local transitions. Choose a sleeve that installs without excessive stretching yet remains close enough to avoid snagging or uncontrolled movement. Review bend radius, flex frequency, rubbing points, temperature, hydraulic fluids, outdoor exposure and the method used to secure each end. For applications requiring protection against high-pressure fluid spray or hose bursts, the sleeve's suitability should be verified under the relevant operating and test conditions.
Customization Available
• Diameter and Bundle Fit - Select suitable sleeve sizes based on the outside diameter of individual hoses or multi-hose bundles.
• Cut Lengths and Tolerances - Customized cut lengths and tolerance control to meet the requirements of specific machine zones, hose kits, or assembly stations.
• Color and Identification - Black is the standard color; printed labels or other identification options can be evaluated upon request.
• Packaging - Available in rolls, bags, kits, and customized OEM cartons.
• Incoming yarn verification - Material identity and agreed purchasing requirements are checked before production.
• Wall and construction checks - Nominal thickness and textile build are measured according to the approved inspection plan.
• Size and fit review - Finished diameter and sample fit are compared with the confirmed hose or bundle dimensions.
• Workmanship inspection - The sleeve is examined for yarn damage, contamination, uneven coverage and unacceptable openings.
• Order conformity - Length, marking, end finish, quantity and packaging are checked against the released order.
Frequently Asked Questions
01. What is the main difference between the 1.0 mm and 0.8 mm versions?
The 1.0 mm option provides a more substantial textile wall for routes that need greater external coverage. Final selection should still consider clearance, movement and the actual abrasion point.
02. Should I size the sleeve from the hydraulic hose bore?
No. Use the measured outside diameter of the hose or complete bundle, including the largest transition that the sleeve must pass over.
03.Can HPS-NY-S-T10 be used on moving hose routes?
It can be considered for moving routes when diameter, bend radius, flex frequency, anchoring and contact surfaces are reviewed together.
04. What information is needed for a custom order?
Provide hose and fitting dimensions, route movement, contact points, environment, length, end treatment, marking, packing and annual quantity.
Request a Sample or Quote
Send the hose or bundle outside diameter, routing conditions, abrasion points, temperature, fluid exposure, finished length and order quantity. MJ FLEX will review the fit and arrange a HPS-NY-S-T10 sample or quotation.
