Why Choose ZTW-PZP Zipper Cable Sock?
1. Create a clean finished cable route
Opaque textile construction conceals mixed cable colors and irregular bundle shapes.
2. Keep the wrap securely closed
The zipper provides a positive closure for handling, movement and daily use.
3. Protect nearby people and surfaces
A soft fabric exterior reduces direct contact with loose wires and rough bundle edges.
4. Retain service access
The sleeve unzips along its length for planned inspection and cable replacement.
1. Full-length zip-up closure
Delivers secure enclosure with repeatable access.
2. Opaque textile body
Improves visual containment compared with open-mesh braid.
3. Smooth exterior surface
Provides a soft interface around furniture, panels and occupied spaces.
4. Retrofit wrap-around installation
Fits assembled cable runs without passing over connectors.
5. Flexible cable routing
Follows bends and helps control loose or mismatched wires.
6. Optional mixed-line use
Can organize selected hoses with cables after compatibility review.
7. Project-specific finishing
Widths, lengths, zipper orientation, labels and packing can be customized.
| Sleeving Material |
Polyester textile |
| Zipper Material |
Nylon |
| Structure |
Flat zip-up wrap |
| Closure |
Full-length zipper |
| Working Temperature |
-40°C to +125°C |
| Melting Point |
240±10°C |
| Flammability |
UL94 V2 |
| Abrasion Resistance |
Medium |
| Standard Color |
Black |
| Certification |
RoHS,REACH |
| Cutting Tool |
Blade or hot knife |
Specifications
|
Part No
|
Flat Width
(mm)
|
ID
(mm)
|
Max Bundle Dia
(mm)
|
Packing
Length
|
|
|
ZBW-PZP-012-BK
|
12
|
Φ8
|
8
|
Custom Lengths |
|
ZBW-PZP-020-BK
|
20
|
Φ12
|
15
|
Custom Lengths |
|
ZBW-PZP-030-BK
|
30
|
Φ20
|
22
|
Custom Lengths |
|
ZBW-PZP-040-BK
|
40
|
Φ25 |
27
|
Custom Lengths |
|
ZBW-PZP-050-BK
|
50
|
Φ32 |
35
|
Custom Lengths |
|
ZBW-PZP-064-BK
|
64
|
Φ40
|
45
|
Custom Lengths |
Typical Applications
Office furniture and conference rooms
Conceals power, data and display cables for a cleaner, safer-looking installation.
Passenger and vehicle interiors
Contains auxiliary wiring near trim, seating and service panels.
Medical and laboratory equipment
Organizes accessible leads and tubing with a soft, wipeable-looking exterior; cleaning compatibility must be confirmed.
Exhibition and retail displays
Hides mixed temporary wiring while allowing fast reconfiguration.
Industrial operator stations
Protects and contains cable groups near consoles without permanent conduit.
Measure the maximum bundle circumference, not only the nominal diameter, and include connectors or hose fittings that remain inside the sleeve. Allow clearance so the zipper closes without trapping cables or loading the seam. Specify appearance, cleaning exposure, bend radius, movement, opening frequency and whether hoses are included.
Customization Available
• Sleeve width and length — Made to the cable route and required closure allowance.
• Fabric and color — Surface, weight and color options subject to material and MOQ review.
• Zipper configuration — Slider direction, zipper color and end construction can be specified.
• Assembly packaging — Individual bags, installation kits, labels and OEM branding available.
ZTW-PZP is not inherently waterproof, fluid tight or pressure retaining. Any flame, low-smoke, chemical, cleanability or biocompatibility requirement must be validated for the complete construction, including fabric, zipper and sewing thread. Applicable material declarations can be supplied for a confirmed order.
• Textile surface inspection — Weave, appearance, contamination and edge quality are monitored.
• Seam and zipper inspection — Stitching, alignment, slider travel and end security are checked.
• Finished-fit verification — Width, length and closure clearance are measured.
• Traceable shipment release — Labels, quantity, packaging and customization details are confirmed.
Frequently Asked Questions
01. Is the textile sleeve waterproof?
No. Standard ZTW-PZP is not a sealed waterproof enclosure.
02.Can it be used for a visible office cable run?
Yes. Its opaque textile body is designed to create a cleaner, contained appearance.
03. What is the advantage over a braided zipper sleeve?
The textile version provides denser visual coverage and a smoother continuous outer surface.
Request a Sample or Quote
Send the bundle dimensions, installation environment, closure preference, finished length, quantity and required documents. MJ FLEX will review the application and recommend a suitable sample or quotation configuration.
