PPS Expandable Sleeving
PPS Cable Sleeving
expandable sleeve cable
PPS Braided Sleeving
expandable pps sleeve

PPS Expandable Braided Cable Sleeve

MJ FLEX BRS-PPS is an expandable cable sleeve braided from polyphenylene sulfide monofilament. PPS provides a balanced combination of thermal stability, chemical resistance, dimensional control and electrical performance for cable systems exposed to heat, fluids and demanding industrial environments.

  • Material :

    PPS

  • Working Temperature :

    -70℃~ +200℃

  • Melting Point :

    280+(-)10℃

  • Flammability :

    VW-1,UL 94 V-0

  • Standard Color :

    Black

  • Certification :

    Rohs,Reach,Halogen Free

  • MOQ :

    500m

  • Why Choose BRS-PPS PPS Expandable Sleeving?

    • Protect cables in sustained heat

    PPS retains useful mechanical properties where standard PET or nylon may lose stability.

    • Handle aggressive industrial fluids

    The polymer offers broad resistance to many fuels, oils, solvents and process chemicals.

    • Maintain compact harness routing

    Expandable braid follows bends and diameter changes without rigid conduit.

    • Balance performance and cost

    PPS is a practical intermediate choice when PET is insufficient but PEEK is not required.



    Key Features

    1. PPS monofilament construction

    Provides heat-stable cable protection.

    2. Expandable braided geometry

    Fits a defined range of bundle diameters.

    3. Broad chemical resistance

    Supports use around industrial fluids after compatibility review.

    4. Low moisture uptake

    Helps maintain dimensions in humid environments.

    5. Abrasion protection

    Reduces cable-jacket wear against equipment structures.

    6. Electrical insulation support

     Nonconductive braid separates cables from nearby surfaces.

    7. Custom OEM supply

    Sizes, braid density, cut lengths and packaging can be reviewed.



    Technical Data

    Material PPS monofilament
    Construction Expandable braid
    Working Temperature -70°C to +200°C
    Melting Point 280±10°C
    Flammability VW-1,UL 94 V-0
    Abrasion Resistance Very High
    Standard Color Black
    RoHS Compliant Yes
    Reach Compliant Yes
    Halogen Free Yes
    UV Resistant Yes
    Cutting Tool Hot knife or project method
    Supply Rolls or cut lengths

    Specifications
    Part No
    Flat Width(W)
    Expanded Range(mm)
    Packing
    Length
    (m/spool)
    Inch
    mm
    Min.(I)
    Max.(O)
    BRS-PPS-003-BK
    1/8”
    		 3 1 6 1000
    BRS-PPS-006-BK
    1/4”
    		 6 3 9 500
    BRS-PPS-008-BK
    5/16”
    		 8 5 12 350
    BRS-PPS-010-BK
    3/8”
    		 10 7 17 350
    BRS-PPS-012-BK
    1/2”
    		 12 8 20 350
    BRS-PPS-016-BK
    5/8”
    		 16 10 27 250
    BRS-PPS-018-BK
    11/16"
    		 18 12 29 250
    BRS-PPS-020-BK
    3/4”
    		 20 14 32 200
    BRS-PPS-025-BK
    1”
    		 25 18 35 200
    BRS-PPS-032-BK
    1-1/4”
    		 32 20 50 150
    BRS-PPS-038-BK
    1-1/2”
    		 38 30 60 100
    BRS-PPS-045-BK
    1-3/4”
    		 45 35 75 100
    BRS-PPS-050-BK
    2”
    		 50 40 80 100
    BRS-PPS-064-BK
    2-1/2”
    		 64 45 105 50
    BRS-PPS-076-BK
    3”
    		 76 64 120 50
    BRS-PPS-100-BK
    4”
    		 100 80 150 50
    ● Note: Expanded range describes geometric capability, not the preferred continuous operating point. Selecting near maximum expansion increases braid openings, reduces surface coverage and shortens installed length.

    Typical Applications
    Automotive under-hood harnesses
    Protects wiring near heat, oils and automotive fluids after application validation.
    Industrial machinery
    Covers sensor and control cables exposed to process heat and chemicals.
    Electrical equipment
    Organizes internal wiring where dimensional stability and electrical properties matter.
    Chemical processing equipment
    Protects instrument cables subject to selected solvent or chemical exposure.
    Appliances and heating systems
    Provides a higher-temperature alternative to general-purpose polymer sleeving.


    How to Select

    Provide continuous and peak temperature, chemical exposure, bundle range, bend radius, abrasion source and required documents. Confirm the exact yarn grade before publishing a temperature or flame



    Customization Options

    Diameter and expansion - Matched to minimum and maximum bundle size.

    Braid density - Adjusted for coverage, flexibility and weight.

    Cut lengths - Prepared pieces for repeatable assembly.

    Labels and packaging - Project identification, reels, bags and OEM cartons.

    Testing and Compliance

    RoHS, REACH and halogen-related declarations may be available for confirmed materials. Any UL 94, automotive, railway or temperature statement must match the exact yarn and sleeve construction. Final compliance remains the responsibility of the complete cable assembly.



    Quality Assurance

    Material verification - PPS yarn identity and color are checked.

    Braid inspection - Coverage, broken filaments and surface defects are monitored.

    Dimensional control - Nominal size, expansion and length are verified.

    Release inspection - Labels, quantity and packaging are checked.

    Frequently Asked Questions

    01. When should PPS be selected over PET?
    Choose PPS when the application needs greater heat stability and chemical resistance.depends on the exact yarn and braid construction.
    02. Is PPS sleeving flame rated?
    Only if the exact finished construction has supporting test data.
    03. Can it be supplied in cut lengths?
    Yes, subject to cut tolerance, end finish and MOQ review.



    Request a Sample or Quote

      Send the bundle range, operating environment, required performance, cut length, quantity and documents. MJ FLEX will recommend a suitable construction and arrange a sample or quotation.
